Waterproof DC Socket DC Jack High-Current DC Power Socket – GSC-DCJ-0003
DC powerThrough-HoleRight AngleWaterproof
GSC-DCJ-0003 is a DC power connector, horizontal waterproof IPX7 ￠1.35mm (board-mounted plug-in type) DC socket. GSCONN part GSC-DCJ-0003.
WaterproofRated waterproof construction
Through-HolePCB solder termination
5,000 CyclesRated mating life
Technical Specifications
| Series | DC JACK |
| Type | Waterproof rating IPX7 |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–35 N |
Key Features
- Horizontal waterproof IPX7 ￠1.35mm (board-mounted plug-in type) DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0003 is a DC power connector, horizontal waterproof IPX7 ￠1.35mm (board-mounted plug-in type) DC socket.
| Series | DC JACK |
|---|---|
| Type | Waterproof rating IPX7 |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–35 N |
