DC Socket DC Jack On-Board Plug-in DC Power Socket – GSC-DCJ-0105
DC power4 PinThrough-Hole
GSC-DCJ-0105 is a DC power 4-contact connector, screw-terminal type, ￠2.0 & 2.5 mm, high-current (board-mount plug-in) DC socket. GSCONN part GSC-DCJ-0105.
Through-HolePCB solder termination
5,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | Flush-mounted / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- Screw‑terminal type
- ￠2.0 & 2.5 mm
- high‑current (board‑mount plug‑in) DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0105 is a DC power 4-contact connector, screw-terminal type, ￠2.0 & 2.5 mm, high-current (board-mount plug-in) DC socket.
| Series | DC JACK |
|---|---|
| Type | Flush-mounted / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
