TDxx01610000G PCB Terminal Block 10.0mm Amphenol Anytek | GSCONN
10.0mm16A250VcULus
Built for demanding automation and control applications, this Anytek T-series 10.0mm pitch PCB terminal block delivers 16A continuous current and 250V rated voltage for motor...
10.0mm pitch engineering-gradePower-circuit spacing
16A high-current capacityMotor control wiring
Wave-solder compatibleThrough-hole PCB pins
cULus/VDE listedVDE
Technical Specifications
| Certification | cULus, UL, TUV |
| Mounting | PCB Mount |
| Number of Poles | 1~12 |
| Pitch | 10.0mm |
| Rated Current | 16A |
| Rated Voltage | 250V |
| Wire Gauge | AWG14 |
Key Features
- Precision 10.0mm centerline spacing optimized for high-isolation PCB layouts
- Rated current 16A continuous and voltage 250V for reliable industrial-grade performance
- Green PA66 housing with brass tin-plated contacts for low contact resistance
- Captive screw clamping mechanism with M3.5 steel screws for vibration-resistant termination
- Compatible with wire sizes AWG24-12 for flexible installation requirements
- Certified to VDE for global market deployment
- Compatible with PCB test fixtures and bed-of-nails test systems
- Suitable for switchgear and power distribution panel wiring
Applications
- Industrial Automation
Drawing & Dimensions
Built for demanding automation and control applications, this Anytek T-series 10.0mm pitch PCB terminal block delivers 16A continuous current and 250V rated voltage for motor control wiring. 8-position configuration supports flexible system integration. Suitable for use in industrial automation, building controls, and instrumentation panels. Each unit ships with captive screws pre-installed for immediate PCB placement. Compatible with industry-standard wave and selective soldering processes, this terminal block is qualified for use in industrial control panels, power-distribution boards, and instrumentation systems. RoHS and REACH compliant materials support global market deployment.
