TRxx2551A000G PCB Terminal Block 5.0mm Amphenol Anytek | GSCONN
5.0mm20A300VcULus
Optimized for compact industrial control board designs, this Anytek T-series 5.0mm pitch PCB terminal block delivers 20A continuous current and 300V rated voltage for high-current...
Compact 5.0mm centerlineStandard PCB pitch
20A low-resistance pathHigh-current load circuits
Reflow-solder compatibleThrough-hole PCB pins
cULus/VDE listedVDE
Technical Specifications
| Certification | cULus, UL, TUV |
| Mounting | PCB Mount |
| Number of Poles | 1~24 |
| Pitch | 5.0mm |
| Rated Current | 20A |
| Rated Voltage | 300V |
| Wire Gauge | AWG12-22 |
Key Features
- Precision 5.0mm centerline spacing optimized for balanced-density PCB layouts
- Rated current 20A continuous and voltage 300V for reliable industrial-grade performance
- Green PA66 housing with brass tin-plated contacts for low contact resistance
- Captive screw clamping mechanism with M2.5 steel screws for vibration-resistant termination
- Compatible with wire sizes AWG22-12 for flexible installation requirements
- Certified to VDE for global market deployment
- Compatible with industrial robot controller signal paths
- Compatible with wave and reflow soldering processes for volume production
Applications
- Industrial Automation
Drawing & Dimensions
Optimized for compact industrial control board designs, this Anytek T-series 5.0mm pitch PCB terminal block delivers 20A continuous current and 300V rated voltage for high-current load circuits. 8-position configuration supports flexible system integration. Available in 8-position configurations; multi-pole ganging supported via dovetail interlocks. Each unit ships with captive screws pre-installed for immediate PCB placement. Compatible with industry-standard wave and selective soldering processes, this terminal block is qualified for use in industrial control panels, power-distribution boards, and instrumentation systems. RoHS and REACH compliant materials support global market deployment.
